Evolution Profi

Bomech is responding to the growing international demand and is presenting a new series of dribble bar systems with working widths of 21 and 24 m. Flexibility is guaranteed: the 24 m can also be operated at 18 m thanks to additional folding arms of 3 m on both sides. All models ensure precise distribution with a hose spacing of 25 cm and 50 mm outlets. In addition, the new line comes with a patented drop-stop system that makes it possible to lift and lower the hoses in any position. Hydraulic cushioning cylinders are specially designed to let the dribble bar move smoothly during braking or lifting, providing extra protection and long-lasting durability.

Automatic height control system
The new 24 and 21 m dribble bar systems are equipped with a state-of-the-art height control system. Special sensors control both booms separately, ensuring that the optimal distance to the ground is always maintained and that the slurry is precisely applied. This automatic system also relieves the driver since no manual height adjustments are needed.

Alrena precision macerators
The new dribble bar series is equipped with 2 Alrena macerators on each dribble bar. This not only guarantees a large flow rate, but also minimises the V-formation at the start of the slurry spreading.

  1. Standard hose distance 25 cm
  2. Hose outlet diameter 50 mm
  3. Collision protection on 24 m and 21 m versions
  4. Patented drop-stop system with folding cylinders
  5. Transport width 2.99 m for tank diameters up to 2.2 m (mounting on wider tankers possible)
  6. Various section control options available (mechanical, hydraulic or with the Alrena ASC system)
  7. Sensor-controlled height adjustment system for both main arms
  8. All hydraulic cylinders have end cushioning for maximum performance and gentle folding
